Processor : High – Performance Embedded SOC Processor
Operation System : Embedded Linux Operation System
CAMERA : CMOS Low Illumination 1.0 MP HD Colorful Camera
Video Compression Standard : H.264
Display Screen : 10.1 – Inch ColorFul TFT LCD
Display Resolution : 1280 * 800
Operation Metod : Physical Keypad
Operation Interface : LCD Display , Easy Menu
Audio Outpot : Build – in LoudSpeaker
Audio Compression Standard : G.711
Audio Compression Rate : 4 Kbps
Audio Quality : Noise Suppression and Echo Cancellation
Internal Card Reader : Build – in IC Card Reader
External Card Reader : Wiegand 26 , Wiegand 34 , Or RS-485 IC Reader
Door Magnetic Detection : Detects Door Magnetic Status
Light Supplement Mode : Visible Light Supplement
Eternet : 10/100/1000 Mbps self-adaptive Ethernet
Network Protocol : TCP/IP
Netword InterFace : 1RJ/45 10/100/1000 Mbps self-adaptive Ethernet InterFace
Material : Alominum Alloy
Power Supply : DC15V or POE Powered
Power Consumption : < 15 W
Working Temperature : -40*C to +60*C (-40*F to 140*F )
Working Humidity : 10% to 90%
IP Protection Level : IP65
Dimensions ( L * W * H ) : 338 * 190 * 31mm
Certification : FCC , CE , ROUS , REACH , WEEE , RCM , RED , COC
